GT40 Part CAD Models

Hi Dylan
Great cad work... I have a CNC mill and can make parts off the STEP or IGES files that you post.

I have a cast rear upright like the ones you've posted and designed a front upright but haven't made it yet or run it through FEA to make sure its OK.
Do you have a front upright modeled?


Cheers Craig Young


Attachments

Neat part Craig! I don't have a front upright modeled. I went with a Wilwood Pro Spindle and found a model on GrabCad, so I had no need to model it.

I have a rather large model being made in collaboration with someone else that hopefully should be finished soon...to all of you looking for transaxle models ;)

Dylan,

I see a lot of folks making door braces and other things that are enhancements to the cars. Items like door braces and rear clip hinges. Any plans on uploading any of these type things in the future?

Robert

Hi Robert,

I'm still in the middle of doing suspension on mine, and am nowhere near the stage where I will be designing the door braces and body hinges and mounts. I'd like to upload whatever can be used by the community, so I'll update this thread and GrabCad as I produce the parts.

Neat part Craig! I don't have a front upright modeled. I went with a Wilwood Pro Spindle and found a model on GrabCad, so I had no need to model it.

I have a rather large model being made in collaboration with someone else that hopefully should be finished soon...to all of you looking for transaxle models ;)
The steering arm in the model that i found on Grabcad was different to the length listed on the Wilwood site.




Ryan, what model on GrabCAD, (It isn't one of mine,) and what Wilwood part number are you referring to?
